Hi MikeGre
I was able to find out that this is a known issue. You may be able to use this widget script as a workaround until the issue is resolved.
/*
Welcome to your Widget's Script.
To learn how you can access the Widget and Dashboard objects, see the online documentation at https://sisense.dev/guides/js/extensions
*/
var filtersAddedFromSunburst = [];
widget.on('ready', function(widget, event) {
// limit selector scope to this widgetid, in case there is more than one sunburst widget
var widgetid = element.parent().attr('widgetid');
var this_widget_selector = "widget[widgetid='" + widgetid + "']";
var this_toolbar_selector = "widget[widgetid='" + widgetid + "'] widget-toolbar";
var this_sunburst_selector = "widget[widgetid='" + widgetid + "'] .chart > svg >g > path";
//check if there are existing filters that were applied by this sunburst, and they are not currently set to 'include all'
//used in decision on whether to show 'clear selection' button or not.
let areThereFilters = checkIfFiltersExistForSunburstDims();
//check if button is already there - so not to add it more than once
let existingBtn = $('button[id="clear-selection-' + widgetid + '"]')
let doesClearButtonExist = existingBtn.length > 0 ? true : false;
if (areThereFilters && !doesClearButtonExist) {
//create the 'clear selection button
let btn = $('<button id="clear-selection-' + widgetid + '">Clear Selection</button>')
.on("click", function(event) {
clearSunburstFilters();
});
let elemToolbar = $(this_toolbar_selector);
elemToolbar.prepend(btn);
} else if (!areThereFilters) {
//if filters are reset to 'include all' or deleted then remove the button
$('button[id=clear-selection-' + widgetid + ']').remove();
}
// select d3 segment elements, add onclick function to add dashboard filter
var sunburst_chart_segments = $(this_sunburst_selector)
.css({
cursor: 'pointer'
})
.on("click", function(event) {
// getting all the relevant JAQL info from the segment
let panelDepth = this.__data__.depth - 1;
let dim = widget.metadata.panels[0].items[panelDepth].jaql.dim;
let column = widget.metadata.panels[0].items[panelDepth].jaql.column;
let datatype = widget.metadata.panels[0].items[panelDepth].jaql.datatype;
let table = widget.metadata.panels[0].items[panelDepth].jaql.table;
let title = widget.metadata.panels[0].items[panelDepth].jaql.title;
//2023.3 moved the name attribute for the selected value to __data__.data.name
let selectedVal = this.__data__.data ? this.__data__.data.name : this.__data__.name;
let filterJaql = {
jaql: {
'column': column,
'datatype': datatype,
'dim': dim,
'filter': {
'explicit': true,
'members': [selectedVal],
'multiSelection': true
},
'table': table,
'title': title
}
};
let options = {
refresh: true,
save: true,
unionIfSameDimensionAndSameType: true,
reason: 'widgetSelection'
};
let selectionDataItem = {
'dim': dim,
'members': [selectedVal]
};
//add filter to array, to be able to check later which filters to clear
//check if it already exists first, to avoid duplicates
let sbFilterAlreadyExistsIndex = filtersAddedFromSunburst.findIndex(getFilterIndexForDim, filterJaql.jaql.dim);
if (sbFilterAlreadyExistsIndex != -1) {
//already exists, so remove it - will be re-added with new selection
filtersAddedFromSunburst.splice(sbFilterAlreadyExistsIndex, 1);
}
filtersAddedFromSunburst.push(filterJaql);
// setting the new filter from the segment info
widget.dashboard.filters.update([filterJaql], options);
});
})
function checkIfFiltersExistForSunburstDims() {
let filterCount = 0
//as sunburst is cliced to filter, we store the filter selection in filtersAddedFromSunburst array
filtersAddedFromSunburst.forEach(sbFilter => {
let filteredDim = sbFilter.jaql.dim;
//find the dashboard filter object for our stored filter reference
let dashFilterIndex = widget.dashboard.filters.$$items.findIndex(getFilterIndexForDim, filteredDim);
//store the index for the matching filter in our array, so we can use it to reset that filter on 'clear selection' click
sbFilter.dashboardFilterIndex = dashFilterIndex;
let isDashFilterIncludeAll = widget.dashboard.filters.$$items[dashFilterIndex].jaql.filter.all;
if (dashFilterIndex > -1 && !isDashFilterIncludeAll) {
filterCount = filterCount + 1
}
});
//if there is one or more filters that were applied from the sunburst AND they are not currently set to 'include all' then return true
return filterCount > 0;
}
function getFilterIndexForDim(flt) {
return flt.jaql.dim === this.toString();
}
function clearSunburstFilters() {
//loop through filters that were updated by clicking this sunburst
filtersAddedFromSunburst.forEach(sbFilter => {
//copy the filter to a new variable
let flt = widget.dashboard.filters.$$items[sbFilter.dashboardFilterIndex];
//set filter to include all = clearing the filter
flt.jaql.filter.all = true;
flt.jaql.filter.explicit = false;
let options = {
refresh: true,
save: true,
unionIfSameDimensionAndSameType: true,
reason: 'widgetSelection'
};
//update the dashboard filter to be 'include all' = clearing the filter
widget.dashboard.filters.update([flt], options);
});
}
